EVO Lite+ — 6K 1-Inch Sensor Camera Drone
Prosumer camera drone with a 1-inch 20 MP sensor, 6K/30 HDR video, adjustable f/2.8–f/11 aperture and 40-minute flights — cinematic quality in a 835 g airframe.
Flight Time
40 min
Camera
6K 1" CMOS
Range
12 km
Weight
835 g
Wind Resistance
10.7 m/s
Max Speed
18 m/s
- ✓1-inch 20 MP sensor with adjustable f/2.8–f/11 aperture
- ✓6K/30 HDR video, 10-bit color, 4-axis gimbal stabilization
- ✓40 min max flight time — class-leading endurance
- ✓Ultra-wide-angle three-way obstacle avoidance
- ✓SkyLink transmission up to 12 km (FCC) with 1080p live feed
Full Specifications
Aircraft
Dimensions (including blades)
Folded: 210×123×95mm Unfolded: 433×516×95mm
Wheelbase
368mm
Max ascent speed
5 m/s (ludicrous), 4 m/s (standard), 3 m/s (smooth)
Max descent speed
4 m/s (ludicrous), 3 m/s (standard), 2 m/s (smooth)
Max level flight speed(no wind, near sea level)
18 m/s (ludicrous), 10 m/s (standard), 5 m/s (smooth)
Maximum Service Ceiling Above Sea Level
3000m
Max flight time (no wind)
40min
Max hovering time (no wind)
38min
Max flight distance (no wind)
24km
Maximum Wind Speed Resistance
10.7m/s
Max tilt angle
33° (ludicrous), 25° (standard), 25° (smooth)
Max angular velocity
200° (ludicrous), 120° (standard), 60° (smooth)
Operating temperature
-10°C~40°C
Operating frequency*
2.400–2.4835GHz, 5.725–5.850GHz, 5.150–5.250GHz
Transmission power (EIRP)
FCC:≤30dBm; CE:≤20dBm
GNSS
GPS, GLONASS, Galileo
Hovering accuracy
Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning);
Max transmission distance (unobstructed, free of interference)
FCC: 12km; CE: 6km
Max battery life
~ 2.5h (when connected to a mobile phone) ~ 3.5h (when not connected to mobile phone)
Interface type
Type C
Transmission system
Autel SkyLink
Realtime transmission quality
Transmission distance<1km: 2.7K 30fps Transmission distance>1km: 1080P 30fps
Transmission bitrate
90Mbps
Transmission delay
≤ 200 ms**
Smartphone/Tablet holder size
Length ∞, Width 83mm, Height 13mm
Voltage
11.13V
Max charging voltage
12.75V
Battery Type
Li-Po 3S
Energy
68.7Wh
Charging temperature
5~45°C
Single battery charging time
90min
Max charging power
78W
Camera & Gimbal
Mechanical range
Pitch: -135°~45° Roll: -45°~45° Yaw: -90°~90°
Controllable range
Pitch: -90°~ +30° Yaw: -80°~ +80°
Stabilization
3-axis
Max control speed (pitch)
30°/s
Angular vibration range
±0.003°
Lens
FOV: 82° Equivalent focal length: 29mm Aperture: f/2.8 ~ f11 Focus range: 0.5m ~ ∞ Focus mode: CDAF/MF
ISO range
Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400 Night scene mode: ISO up to 48000
Shutter speed
Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates
Portrait blur
Real-time image transmission portrait blur and photo portrait blur
Defog mode
Support
Zoom range
Digital zoom: 1 ~ 16 times Lossless zoom: 4K: 1.3 times; 1080p: 3 times Note: 6K: Digital zoom 4K: more than 1.3 times the digital, the following is lossless 1080P: more than 3 times the digital, the following is lossless
Photo format
JPG(8-bit) / DNG(10-bit) / JPG+DNG
Photo resolution
5472x3648 (3:2) 5472x3076 (16:9) 3840x2160 (16:9)
Photo shooting mode
Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG minimum 5s) HDR imaging: 5472x3648/3840x2160 HyperLight: 5472x3648/3840x2160
Video coding format
H265/H264
Video format
MP4/MOV(8-bit)
Video resolution
5472x3076 p30/25/24 3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 HDR: 3840x2160 p30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p60/50/48/30/25/24
Max bitrate
120Mbps
Timelapse
Original image: 5472*3076/3840*2160, JPG/DNG Video: 5.4K/4K P25
Panorama
Horizontal/Vertical/Wide-angle/Spherical Original image: 5472*3648, JPG/DNG
Supported file system
Fat32, exFat
WIFI transfer
20MB/s
Obstacle Avoidance
Forward
Accurate measurement range: 0.5~18m Effective sensing speed:<12m/s FOV: horizontal<70°, vertical <88°
Backward
Accurate measurement range: 0.5~18m Effective sensing speed:<12m/s FOV: horizontal<40°, vertical <30°
Downward
Accurate measurement range: 0.5~22m Visual hovering range: 0.5~40m FOV: horizontal<40°, vertical <30°
Operating environment
Forward, backward: Surface with clear pattern and adequate lighting(lux> 15) Downward: Surface with clear pattern and adequate lighting(lux> 15); Detects diffuse reflective surfaces(>20%) (walls, trees, people, etc.)
Battery & Charger
Input
100–240V/50–60HZ
Output
12.75V 5A
Rated power
63.75W
App & Storage
Mobile App
Autel Sky
Mobile system required
iOS 13.0 and above Android 6.0 and above
Built-in storage
6GB
SD storage
max. support 256GB(UHS-3 rating required)
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
