EVO-NANO28 min
EVO Nano+ — 249 g Pocket 4K Camera Drone
Under-250 g class drone that folds to pocket size — 50 MP photos, 4K/30 video, 28-minute flights and 10 km transmission. No registration required in most regions.
Flight Time
28 min
Camera
50 MP 1/1.28" CMOS
Range
10 km
Weight
249 g
Wind Resistance
7.9 m/s
Max Speed
15 m/s
- ✓249 g takeoff weight — pocket-size, folds flat
- ✓50 MP photos and 4K/30 video on a 1/1.28-inch sensor
- ✓28 min max flight time, 10 km FCC transmission
- ✓Three-way obstacle sensing with precision hover
- ✓One-tap SkyPortrait and Dynamic Track 2.1 subject tracking
Full Specifications
Aircraft
Takeoff Weight (withou t Accessories)
249g
Dimensions (including blades)
Folded: 142×94×55mmUnfolded: 260×325×55mm
Wheelbase
231mm
Max Ascent Speed
5 m/s (ludicrous), 4 m/s (standard), 3 m/s (smooth)
Max Level Flight Speed
4 m/s (ludicrous), 3 m/s (standard), 2 m/s (smooth)
Max Level Flight Speed(no wind, near sea level)
15 m/s (ludicrous), 10 m/s (standard), 5 m/s (smooth)
Max Takeoff Altitude
4000m
Max Flight Time (no wind)
28min
Max Hovering Time (no wind)
26min
Max Flight Distance (no wind)
16.8km
Maximum Wind Speed Resistance
7.9 m/s (Take-off and landing)
Max Tilt Angle
33° (ludicrous), 25° (standard), 25° (smooth)
Max Angular Velocity
200° (ludicrous), 120° (standard), 60° (smooth)
Operating Temperature
-10°C~40°C
Operating Frequency
2.400–2.4835GHz，5.725–5.850GHz,5.150–5.250GHz
Transmission Power (EIRP)
FCC: ≤30dBm; CE: ≤20dBm
GNSS
GPS, GLONASS, Galileo
Hovering Accuracy
Vertical: ±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal: ±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning);
Operating frequency*
2.400–2.4835GHz, 5.725–5.850GHz, 5.150–5.250GHz
Max transmission distance (unobstructed, free of interference)
FCC: 10km; CE: 5km
Operating temperature
0°C ~40°C
Transmission power (EIRP)
FCC:≤30dBm; CE:≤20dBm
Max battery life
~ 2.5h (when connected to a mobile phone)~ 3.5h (when not connected to mobile phone)
Interface type
Type C
Transmission system
Autel SkyLink
Realtime transmission quality
Transmission distance<1km: 2.7K 30fpsTransmission distance>1km: 1080P 30fps
Transmission bitrate
90Mbps
Transmission delay
≤ 200 ms**
Smartphone/Tablet holder size
Length ∞, Width 83mm, Height 13mm
Voltage
7.7V
Max charging voltage
8.8V
Battery Type
Li-Po 2S
Energy
17.32Wh
Charging temperature
5~45°C
Single battery charging time
90min
Max charging power
30W
Camera & Gimbal
Mechanical Range
Pitch: -125°~35°Roll: -34°~33°Yaw: -25°~25°
Controllable Range
Pitch: -90°~ 15°
Stabilization
3-axis
Max Control Speed (pitch)
30°/s
Angular Vibration Range
±0.003°
Lens
FOV: 85°Equivalent focal length: 23mmAperture: f/1.9Focus range: 0.5m ~ ∞Focus mode: PDAF+CDAF/MF
Shooting mode
Automatic mode (P gear): EV adjustable, ISO/Shutter automaticManual mode (M gear): ISO/Shutter adjustable, EV not adjustableShutter priority (S file): Shutter/EV adjustable, ISO automatic
ISO range
Video: ISO100 ~ ISO6400Photo: ISO100 ~ ISO6400
Shutter speed
Photo Mode: 1/8000 ~ 8sOther: 1/8000 ~ 1/frame rates
Portrait blur
Real-time image transmission portrait blur and photo portrait blur
Defog mode
Support
Zoom Range
Digital zoom: 1 to 16 times
Photo format
JPG(8-bit) / DNG(10-bit) / JPG+DNG
Photo resolution
50MP: 8192x6144 (4:3)12.5MP: 4096x3072 (4:3)4K: 3840x2160 (16:9)
Photo shooting mode
Single shotBurst shooing: 3/5Auto exposure bracketing(AEB): 3/5 shotsInterval: 2s/3s/4s/5s (default)/6s/.../60s (DNG minimum 5s)HDR imaging: 3840x2160
Video coding format
H265/H264
Video format
MP4/MOV
Video resolution
3840x2160 p30/25/242720x1528 p30/25/241920x1080 p60/50/48/30/25/24HDR:3840x2160 p30/25/242720x1528 p30/25/241920x1080 p60/50/48/30/25/24
Max bitrate
100Mbps
Timelapse
Original image: 3840*2160, JPG/DNGVideo: 4K P25
Panorama
Horizontal/Vertical/Wide-angle/SphericalOriginal image: 4096*3072, JPG/DNG
Supported file system
Fat32, exFat
WIFI transfer
20MB/s
Zoom range
Digital zoom: 1 ~ 16 times
Video Resolution
3840x2160 p30/25/242720x1528 p30/25/241920x1080 p60/50/48/30/25/24HDR:3840x2160 p30/25/242720x1528 p30/25/241920x1080 p60/50/48/30/25/24
Obstacle Avoidance
Forward
Accurate measurement range: 0.5~16mEffective sensing speed: <10 m/s; FOV: Horizontal<40°,Vertical<30°
Backward
Accurate measurement range: 0.5~18mEffective sensing speed: <12 m/s; FOV: Horizontal<40°,Vertical<30°
Downward
Accurate measurement range: 0.5~20mVisual hovering range: 0.5~40mFOV: Horizontal<40°,Vertical<30°
Operating environment
Forward, backward:Surface with clear pattern and adequate lighting(lux> 15)Downward:Surface with clear pattern and adequate lighting(lux> 15);Detects diffuse reflective surfaces(>20%) (walls, trees, people, etc.)
Battery & Charger
Input
100–240V/50–60HZ
Output
5V 3A,9V 3A,12V 2.5A
Rated power
30W
App & Storage
Mobile App
Autel Sky
Mobile system required
iOS 13.0 and aboveAndroid 6.0 and above
Built-in storage
No
SD storage
max. support 256GB(UHS-3 rating required)
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
