EVO Nest — Autonomous Drone-in-a-Box Station
Self-contained docking station for remote autonomous operations: IP55 enclosure, automated launch/land/charge cycles and cloud control — pairs with EVO Max and EVO II enterprise aircraft.
Flight Time
24/7 operations
Camera
Dock + cloud control
Range
15 km
Weight
60 kg
Wind Resistance
IP55
- ✓Fully automated launch, landing and charging cycles
- ✓IP55 weatherproof enclosure for outdoor deployment
- ✓Cloud control with mission scheduling and live video
- ✓Pairs with EVO Max / EVO II enterprise platforms
- ✓Optional solar power for off-grid sites
Full Specifications
Dock Specifications
Size
36.77 × 25.24 × 30.51 in (hatch closed)
Weight
132 lbs (60 kg)
Protective Level
IP55
Operating Temperature
−22 °F to 131 °F (−30 °C to +55 °C)
Operating Humidity
95 ± 3% (68–86 °F)
Max Operating Altitude
6000 m
Hatch Endurance
≥ 50,000 open/close cycles
Operations & Compatibility
Max Power
1.2 kW
Standby Power
10 W
Operating Voltage
AC 110 V / 220 V
Max Charge Current
16 A
Drone Charge Duration
10% → 90% in 25 minutes
Compatible Aircraft
EVO Max Series (4T / 4N / 4NZ)
Operation Model
Automated launch, landing, charging and data offload
Control
Cloud mission scheduling with live video and telemetry
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
