MAX-4N42 min
EVO Max 4N — Starlight Night-Vision UAV
The night specialist: starlight vision camera that identifies people at 5 km in darkness, plus thermal and wide cameras — the same IP43 EVO Max airframe with 42-minute endurance.
Flight Time
42 min
Camera
Starlight 5 km + thermal + wide
Range
15 km
Weight
1.67 kg
Wind Resistance
12 m/s
Max Speed
17 m/s
- ✓Starlight vision camera — sees people at 5 km at night
- ✓Combined thermal + wide + starlight triple payload
- ✓IP43 weatherproof airframe, flies in low light and rain
- ✓42 min flight time, 15 km FCC transmission
- ✓Radar + vision obstacle avoidance in total darkness
Full Specifications
Aircraft
Weight (Fusion 4N V2 gimbal, battery)
1700 g (ABX41-D smart battery, propellers included)
Maximum Take-Off Mass
1999 g (1890 g for C2 certification in EU)
Fuselage Dimensions
563×657×147 mm (unfolded, incl. propellers)
Diagonal Wheelbase
467 mm
Propeller Size
11 inch, 1158
Propeller Material
Nylon + Carbon Fiber
Max Ascent Speed
Slow: 2.5 m/s · Smooth: 3 m/s · Standard: 6 m/s · Ludicrous: 8 m/s
Max Descent Speed
Slow: 2.5 m/s · Smooth: 3 m/s · Standard: 6 m/s · Ludicrous: 6 m/s
Max Flight Speed
Slow: 2.5 m/s · Smooth: 10 m/s · Standard: 15 m/s · Ludicrous: 17 m/s
Max Service Ceiling Above Sea Level
4500 m (ABX41-D smart battery)
Max Flight Time
42 minutes (windless lab, 8 m/s horizontal)
Max Flight Distance
25 km (windless lab, 14 m/s horizontal)
Max Hover Time
37 minutes (windless lab)
Max Wind Speed Resistance
Takeoff & landing: 10.7 m/s · Cruise: 12 m/s
Max Pitch Angle
Slow: 10° · Smooth/Standard: 30° · Ludicrous: 36°
Hovering Accuracy
Vertical ±0.1 m (visual positioning) / ±0.5 m (GNSS)
GNSS
GPS + Galileo + BeiDou + GLONASS
Operating Temperature
−20 °C to +50 °C (without load); −20 °C to +40 °C (full load)
Internal Storage
128 GB internal storage (64 GB available)
Hot Swap Battery
Supported
Strobe Light
Integrated
Camera & Gimbal
Gimbal Stabilization
3-axis mechanical gimbal (tilt, roll, pan), angular vibration < 0.005°
Starlight Vision Camera
1/1.2" CMOS, 8 MP effective — identifies people at 5 km at night
Wide-Angle Camera
1/2" CMOS, 48 MP effective, DFOV 83.4°, f/1.6
Thermal Camera (Fusion 4N)
640×512 uncooled VOx microbolometer, f/1.0, 8–14 µm, NETD ≤ 50 mK
Thermal Zoom
1–16× digital zoom, linked zoom supported
Night Vision Performance
Starlight sensor works without IR illumination — sees through glass
Temperature Measurement
Center-point / spot / area measurement modes
Video Encoding
H.264/H.265, MP4, up to 60 Mbps
Laser Rangefinder
905 nm, measuring range 5–1200 m, accuracy ±(1 m + D×0.15%)
Radar & Sensing
Millimeter-Wave Radar
60 GHz radar: upward 0.3–20 m, downward 0.15–80 m, forward/backward 0.3–50 m; 24 GHz downward 0.8–12 m
Obstacle Sensing Range
Forward 0.5–30 m, backward 0.5–25 m, side 0.5–15 m (visual)
Radar Capability
All-weather obstacle avoidance — works in rain, dust, smoke and darkness
Flight Modes
Slow / Smooth / Standard / Ludicrous, with custom settings
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
